| Basic Parameters |
|
| Size |
170mm×85mm×23mm/ 6.69×3.35×0.91in |
| Weight |
About 380g |
| Display |
5-inch IPS HD screen, resolution 720 × 1280 |
| Touch Screen |
Industrial multi-touch capacitive screen |
| Expansion slot |
1 SIM, 2 PSAM |
| |
1 MicroSD(TF) |
| Communication Interface |
USB2.0 interface, 3.5 plug charging interface |
| Audio |
Voice broadcast |
| Indicator light |
Network indicator, charging indicator |
| Key |
Scan key, function key |
| Camera (Optional) |
8-megapixel rear camera with flash and autofocus function |
| Flashlight |
Low power LED lighting, used in emergency |
| GPS |
Built-in GPS global positioning system, range error ± 5m |
| Performance Parameters |
|
| CPU |
Quad-core 64-bit Cortex-A53 |
| Memory |
RAM: 2GB, ROM:16GB |
| System |
Android 5.1.1 |
| Extended memory |
Supports up to 32G MicroSD card |
| Data Communication |
|
| 4G |
TDD-LTE Band 38/39/40 |
| |
FDD-LTE Band 1, 2, 3, 4, 7 |
| 3G |
WCDMA(850/1900/2100MHz) |
| WIFI |
2.4G/5G. comply with IEEE 802.11a/b/g/n |
| Bluetooth |
Bluetooth4.0 |
| Working Environment |
|
| Operating temp. |
-20 to 50℃ / -4℉ to 122℉ |
| Storage temp. |
-20 to 70℃/ -4℉ to 158℉ |
| Degree of Protection |
IP65 |
| Battery Performance |
|
| Battery capacity |
Li-polm,4500mAh |
| Stand-by time |
320 hours when turn off the wireless communication and other functions |
| Operating hours |
12 hours or more (full charge) |
| Charging time |
＜4.5hours |
| Barcode Scanning (Optional) |
|
| 1D Barcode |
Scanning module: Honeywell N431X/ others
Code 39, Code 93, Code128, Codebar, EAN-13, EAN- 8, UPC- A, UPC- E, ITF14, UCC/EAN- 128, ITF25, Matrix 25, EAN- 128, ISBNetc
|
| 2D Barcode |
Scanning module: Honeywell-6603/NLS-EM3396/NLS-EM3296
PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode, Postal Codes, US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal etc
|
| RFID (Optional) |
|
| UHF |
ETSI：865～868MHz OR FCC: 902～928MHz |
| |
Working protocol: ISO18000-6C |
| |
Reading Distance: 2m (Ranges depend on tags and environment) |
| HF |
Working frequency: 13.56MHz |
| |
Working protocol: ISO14443A&ISO15693 |
| |
Reading distance: 0～7cm(Ranges depend on tags and environment) |
| LF |
125kHz/134.2kHz |
| PSAM |
2PSAM |
| HF (CPU CARD) |
Read&Write, work only with PSAM |
| Active 2.45G (Custom) |
Reading distance: 200m, 200pcs/time reading
|
| Other Optional Modules |
|
| 433MHz (Custom) |
Reading distance＞200m, reading distance could be customized |
| ZIGBEE (Custom) |
Applicable wireless network data acquisition |
| Infrared (Custom) |
|
| Biological Identification (Optional) |
|
| Module function |
Enrollment, compare and deletion etc |
| Sensor |
TCS1Biological fingerprints /FBI certificated |
| Sensor Type |
Inductive capacitance |
| Image Size |
256×360 pixel |
| Resolution |
500DPI |
| Storage Memory |
1000 fingerprints |
| Accessory |
|
| Standard |
Li-polm battery, charging head, DC cable, USB cable |
| Optional |
Recharging cradle |
| Support |
|
| Documents |
Demo, API, software development guidance |
