Basic parameters
|
|
|
Size
|
166 × 79 × 31 mm
|
|
Weight
|
About 650 g
|
|
Display frequency
|
5.5 inch , 1PS HD screen, resolution 720X1440
|
|
Touch screen
|
Corning Gorilla third-generation industrial-grade multi-touch capacitive screen
|
|
Expansion slot
|
1 Sim card slot (MUP-C785), 1 TF card slot
1 PSAM card slot (MUP-C785)
|
|
Communication Interface
|
1 Type-c interface
|
|
Indicator light
|
Network indicator, charging indicator
|
|
Keyboard
|
Scan button, function button
|
|
Sensor
|
Gravity sensor, light sensor, distance sensor
|
|
Navigation System
|
GPS/Beidou navigation is optional, the error range is ± 5m
|
|
Performance parameter
|
|
|
CPU
|
MT 6771 octa-core 64-bit processor
Four cores A73+four small cores A53, clocked at 2.0GHz
|
|
Memory Capacity
|
RAM: 2GB ROM: 16GB (standard configuration)
RAM: 4GB ROM: 64GB (optional)
|
|
Operating system
|
Android 10.0
|
|
Expand memory
|
Support 256GB Micro T card
|
|
Data communication
|
|
|
4G
|
TD-LTEBand38/39/40/41FDD-LTEBand1,2,3,4,7,17,20
|
|
3G
|
WCDMA (850/1900/2100MHz);
|
|
2G
|
GSM/GPRS/Edge (850/900/1800/1900MHz)
|
|
WIFI
|
2.4G/5G dual frequency, in line with IEEE802.11a/b/g/ac
|
|
Bluetooth
|
Compliant with Bluetooth 4.2
|
|
Working environment
|
|
|
Operating temperature
|
-20℃～50℃
|
|
Storage temperature
|
-20℃～70℃
|
|
Relative humidity
|
5%～95% non-condensing
|
|
Protection level
|
Host IP65
|
|
Battery performance
|
|
|
Battery capacity
|
Two specifications of 4900Ah/9000mAh lithium polymer battery are optional
|
|
Standby time
|
Theoretically turn off wireless communication and other functions, it can stand by for 360 hours
|
|
Charging time
|
Less than 5 hours (support fast charging)
|
|
Operating hours
|
More than 14 hours (full charge once)
|
|
Camera (optional)
|
|
|
Front camera
|
Front 500W pixel camera
|
|
Rear camera
|
Rear 1300W/2000W pixel camera is optional, with flash, auto focus function
|
|
Barcode collection (optional)
|
|
|
One-dimensional code
|
|
|
One-dimensional code laser scanning module
|
HoneywellN431X/other
|
|
Support one-dimensional bar code type
|
Code 39 , Code 93 , Code128 , Codebar , EAN - 13 , EAN - 8 , UPC- A , UPC - E , ITF 14 , UCC/EAN - 128 , ITF25, Matrix25, EAN-128, ISBN, etc.
|
|
QR code
|
|
|
2D scanning engine
|
Zebra SE4710/Zebra SE2100/other
|
|
Support 2D barcode type
|
PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QRcode, MicroQRcode, Aztec, MaxiCode, PostalCodes, USPostNet, USPlanet, UKPostal, AustralianPostal, JapanPostal, DutchPostal, etc.
|
|
RFID (optional)
|
|
|
UHF
|
|
|
Support frequency
|
915MHz, 865MHz (865-868MHz or 902-928MHz)
|
|
Supporting agreement
|
For EPC C1 GEN2 ISO18000-6C protocol
|
|
Reading distance
|
Optional 0-14m/related to label and environment
|
|
HF
|
|
|
Support frequency
|
13.56MHz
|
|
Supporting agreement
|
For ISO15693
|
|
Reading distance
|
0-30cm (related to label and environment)
|
|
Annex
|
|
|
Standard
|
1 lithium battery, 1 charging head, 1 Type-c charging cable
|
|
Optional
|
Backpack, charging stand
|
